NEW BorgWarner S3BGL114 Turbo CAT Earth Moving Truck 3306 10.3L Diesel 178009
BRAND NEW GENUINE BORGWARNER TURBOCHARGER
This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 178009
Interchangeable Number: 167167, 167167R, 167168, 167168R, 178009R, 467167, 467168, 478009
OEM Number: 0R-6829, 0R6829, 110-6979, 1106979, 110-6981, 1106981
Serial Number: 64Z20292-UP
Turbo Model: S3BGL114
Manufacturer: BorgWarner - 3K - Schwitzer, BWTS USA
Year: 1993-
Engine: 3306
Displacement: 10.3L, 10300 ccm
Fuel: Diesel
Power: 224 kW/300 HP
Speed: 2000 RPM
Prefix: 3KS, 64Z, 9TL
Angle α (Compressor Housing): 187/270°
Angle β (Turbine Housing): 0/45°
Actuator: 166513 (2061016552)
Back Plate: 199646 (7C9531, 30-05718)(1800016074)
Bearing Housing: 199732 (199097, 199745)(Oil Cooled)(1900011340B)
CHRA: 167165 (178152, 467165, 478152)(0R6740, 110-7692, 1107692)(1000070032)
Compressor Cover: 198985 (4P9586)
Compressor Wheel: 199097 (4P9803)(167370)(Ind. 60.6 mm, Exd. 86.4 mm, Trim 7.8, 7+7 Blades, Super Back)(1200016469)
Gasket (Oil Inlet): 129119 (210019, 201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900, 129120)(417378 Replaced by 420641)(1900000035)
Gasket (Oil Outlet): 129120 (210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763)(417381 Replaced by 1543360)(1900000025)
Gasket (Turbine Inlet): 132040 (202873, 205396, 205396, 3500683, 210017-0000, 409038-0000, 1S4295, 9749)(1900000003)
Gasket Kit: 318417 (3534521, 3580526)
Heat Shield: 197394 (315964, 317590)(2030016077)
Repair Kit: 318389 (Replace 318386, 318387, 318389)(1252203750, 5000030019)
Turbine Housing: 167161 (1107869)
Turbine Wheel: 167520 (166493)(1151946)(Ind. 83.49 mm, Exd. 73.3 mm, Trim 14.3, 10 Blades)(1100016335)
Application:
1993- Caterpillar Earth Moving with 3306 Engine
1993-07 Caterpillar Truck with 3306 Engine
Caterpillar Industrial with 3306 Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
