NEW Holset HT60 Turbo Cummins N14 Diesel Engine 3800419 3591182

BRAND NEW GENUINE HOLSET TURBOCHARGER

This is a BRAND NEW GENUINE HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 3591182
Interchangeable Number: 3532408, 3534501, 3536098, 3536190, 3536263, 3536805, 3536809, 3536811, 3538400, 3590614, 3591182, 3592512, 359251200H, 3592512H, 3592678, 3800395, 5797-990-2100, 57979902100, 3804632, 3804640, 3804660, 3804806, 4033579, 3592678
OEM Number: 800419, 3800419H, 3800419NX, 3800419RX, 3803721, 3803998, 3804309, 3804502, 380450200, 380450200H, 380450200HX, 3804502H, 3804502HX, 3804502NX, 3804502RX, 3804567, 3804567NX, 3804567RX, 1080005R
Turbo Model: HT60, HT60-N0881A/X27K2
Brand: Holset

Engine: N14
Engine Manufacturer: Cummins
Fuel: Diesel

Angle α (Compressor Housing): 360α
Angle β (Turbine Housing): 360α
Back Plate: 3759618 (3500710, 59618, 166084, 168084, 183472, 143144-0000)(1150704300, 1800016039)
Bearing Housing: 3536097 (3532613)(Oil Cooled)(1900011279)
CHRA: 4027396 (4027396H, 4027794H)(1000020139)
Compressor Cover: 3536424
Compressor Wheel: 3527047 (3519489)(Ind. 73.53 mm, Exd. 108.38 mm, Trim 9.22, 8+8 Blades, Super Back)(1200030106)
Gasket (Oil Outlet): 210018 (3519770, 201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900, 52231586500, 129120)(1900000035)
Gasket (Turbine Inlet): 210532 (Inox Steel)
Gasket Kit: 3800266 (215192)
Heat Shield: 3519155 (18373, 351915500)(2030016126)
Repair Kit: 3575230 (3545669)(1152304750, 1153060752, 5000020037)
Turbine Housing: 3590616
Turbine Wheel: 3594953 (3536189, 3594952, 3526546)(Ind. 97 mm, Exd. 86.2 mm, Trim 17.14, 12 Blades)(1100030011, 1100016108)

Application:
1996-98 Various with Cummins N14 Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
