NEW Garrett T04B31 Turbo John Deere 300 Series Agricultural 6414T 409930-5003

BRAND NEW GENUINE GARRETT TURBOCHARGER

This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 409930-5003
Interchangeable Number: 409930-0003, 409930-5003S, 409930-0001, 409930-5001, 409930-5001S, 409930-0002, 409930-5002, 409930-5002S, 409930-0004, 409930-5004, 409930-5004S, 409930-0005, 409930-5005, 409930-5005S, 409930-0006, 409930-5006, 409930-5006S, 409930-0007, 409930-5007, 409930-5007S, 409930-0008, 409930-5008, 409930-5008S
OEM Number: AR66397, AR69583, AR72166, AR77168, AR87885, AR88181, AR88190, RE19267
Turbo Model: T04B31
Manufacturer: Honeywell-Garrett

Engine: 6359AZ01, 6414T, 6414TT
Emission Standard: Tier 3
Fuel: Diesel

Angle α (Compressor Housing): 348°
Angle β (Turbine Housing): 20°
Back Plate: 408045-0051 (311708, 408045-0034, 408045-0035)(AR101787)(1300016006)
Bearing Housing: 430027-0051 (407285-0019, 430027-0021)(1100030450, 1900011104B)(Oil Cooled)
CHRA: 408105-0100 (408105-5100S, 310283A, 408105-0047, 408105-5047S, 408105-0144, 408105-5144S, 408105-0262, 408105-5262S, 181940, 311443)
Compressor Cover: 408274-0022 (AR57716)
Compressor Wheel: 409179-0022 (AR57715 310094A)(Ind. 49.48 mm, Exd. 74 mm, 8+8 Blades, Billet)(1200016249)
Gasket (Oil Inlet): 210021 (409037-0000, 210021-0000, 311496, 413671-0000, 3519807, R105346)
Gasket (Oil Inlet): 210023 (409036-0000, 210023-0000, 55739, 147837)
Gasket (Turbine Inlet): 409039-0001 (210190-0000, 132044, 312617)(Inox Steel)
Gasket Kit: 409039-0000 (215079, 3524796, 168984, 310063, 188006-0000)
Heat Shield: 409299-0001 (409299-0000)(3524773B)
Repair Kit: 468100-0000 (3524796, 168984, 310063, 188006-0000, 2W0716, 6N7236)(ME078204)(1100040750)
Turbine Housing A/R: 1.15
Turbine Housing: 407316-0021 (AR57717)
Turbine Wheel: 451309-0002 (407276-0005, 410188-0002, 410188-0005, 410188-0014, 446905-0001)(AR57715, 310094A)(Ind. 74.29 mm, Exd. 58.2 mm, 11 Blades)(1100016090)
Turbo Technology: Free Floating

Application:
John Deere 300 Series
John Deere Agricultural with 6414T Engine
John Deere Earth Moving, Crawler, Loader with 6359AZ01, 6414T, 6414TT Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
